| 2012 Harley Davidson Sporster SuperLow XL883L |
The value and quality of confidence SuperLow ™ model in its class. With genuine Harley-Davidson ® rumblings, steel parts, premium paint and chrome immaculate, this model reveals his true roots in American motorcycle every inch of detail.
Dimensions
Length2,215 mm
Seat Height, Laden 648 mm Seat Height, Unladen 695 mm
Ground Clearance100 mm Rake (steering head) (deg)31.1
Trail145 mm Wheelbase1,500 mm
Tires, Front Specification120/70 ZR-18 59WTires, Rear Specification150/60 ZR-17 66W
Fuel Capacity17 l Oil Capacity (w/filter)2.6 l
Weight, As Shipped251 kg Weight, In Running Order260 kg
Luggage Capacity -VolumeN/ALuggage Capacity -WeightN/A
Engine
Engine Air-cooled, Evolution®
Bore76.2 mm
Stroke96.8 mm Displacement883 cc
Compression Ratio9:01Fuel SystemElectronic Sequential Port Fuel Injection (ESPFI)
Drivetrain
Primary DriveChain, 57/34 ratio
Gear Ratios (overall) 1st10.41
Gear Ratios (overall) 2nd7.436Gear Ratios (overall) 3rd5.531
Gear Ratios (overall) 4th4.584Gear Ratios (overall) 5th3.931
Gear Ratios (overall) 6thN/AChassis
ExhaustChrome, staggered, shorty exhaust with dual mufflers
Wheels, Optional Style Type 4N/AWheels, Front Type 4Black, Split 5-Spoke with Machined Rim
Wheels, Rear Type 4Black, Split 5-Spoke with Machined RimBrakes, Caliper TypeDual-piston front, single-piston rear
Parking BrakeN/APerformance
Engine Torque Testing MethodEEC/95/1
Engine Torque 370 Nm Engine Torque (rpm)3,750
Lean Angle, Right (deg.)24.7Lean Angle, Left (deg.)24.4
Fuel Economy: Combined City/Hwy4.6 l/100 km Electric
Lights (as per country regulation), Indicator Lamps 6High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
GaugesHandlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights1Measurement reflects 81.7 kg operator weight.
2Recommended 95 octane or higher fuel (R+M)/2.
3Values shown are nominal. Performance may vary by country and region.
4Standard and optional wheels may vary by country and region.
5Availability of colours may vary from dealer to dealer and is subject to change without further notice.
6Security system includes immobiliser and siren.
7See motorcycle owner’s manual for complete details.
